Brand: Eclipse CCTV
SKU: PRO57
Dimensions: 5.9" x 4.49"
Power: 12VDC
Transmission: Coax
Camera
Sensor: 1/2.5", 5 Megapixel, CMOS
Lens: 3.3mm ~ 12mm Varifocal
Video System: NTSC/PAL
Min. Illumination: Color: 0.001 Lux@F1.2, AGC On; BW: 0 Lux (IR on)
S/N: >52dB (AGC off)
Day/Night: IR-cut filter with auto switch (ICR)
IR Range: Up to 30m (98ft)
Infrared Cut: Removable cut filter, automatic
Video
Video Format: AHD, TVI (selectable)
Resolution: 2592x1944
Frame Rate: 20fps
OSD: Yes (Control Over Coax)
Electronic Shutter: Auto: 1/30s ~ 1/100000s
Video Settings
Automatic Gain Control: Yes
Wide Dynamic Range: Digital
Back Light Compensation: Yes
Auto White Balance: Yes
Digital Noise Reduction: Yes (2D DNR)
Edge Brightness Compensation: Yes
Defogging: Yes
Sharpness: Yes
Smart IR: Yes
HLC: Yes
Supported Languages: English, Chinese
General
Power: 12VDC (+/- 10%), IR off: <1W; IR on: <3.5W
Working Environment: -20°C ~ 50°C, Humidity = 90% RH (non-condensing)
Ingress Protection: IP66, IK10
Dimensions: ∅150mm x 114mm (5.9" x 4.49")
Weight: .9kg (2lbs)
