The RFID Reader with all-metal button from Dahua is equipped with Wiegand 26/34 bits RS-485 protocol. The device features built-in keypad, vandal-resistant, built-in buzzer, watchdog design, and blue backlight. Also, it has red and green indicator LEDs. The reader has a watchdog function to ensure the device is free from halting.
Brand: Dahua
SKU: DHI-ASR1101M
In The Box
RFID Reader with Metal Keypad Buttons
Special Feature: Comes equipped with IK08 rating making it vandal-proof
Dimensions: 4.33 x 3.35 x 1.02 inches
Power: 9 VDC to 15 VDC, 100 mA
Transmission: Wiegand 26/34 or RS485
Service: No monthly fee
System
Main Processor: 8-bit
LCD Display: Red and Green LED Indicators, Blue Backlight
Audible Indicator: Buzzer
Reader
Format: 13.56 MHz MIFARE
Distance: 6.0 to 8.0 cm (2.36 to 3.15 in.)
Response Time: < 0.1 s
Keypad: Metal Button Keypad 12 Keys (1 to 9, *, #), Key 5 has Braille Markings
Interface
To Controller: Wiegand 26/34 or RS485
Certifications
Safety:
EN 60950-1:2006+A11:2009+A1:2010+A12:2001+A2:2013
Conforms to UL Standards
Electromagnetic Compatibility (EMC):
FCC CFR 47 Part 15 subpart B
EN 55032:2015
EN 55024:2010+A1:2015
EN 50130-4:2011+A1:2014
EN 6100-3-2:2014
EN 6100-3-3:2013
Electrical/Environmental
Power Supply: 9 to 15 VDC, 100 mA
Operating Temperature: -30 to +60° C (-22 to +140° F)
Operating Humidity: 95%
Vandal Resistance: IK08
Construction
Color: Black
Dimensions: 110.10 x 85.20 x 26.0 mm (4.33 x 3.35 x 1.02 in.)
Net Weight: 0.50 kg (1.10 lb)
