The RFID Reader (Wiegand) by Dahua features Wiegand Protocol and a default IC MIFARE card. It has a built-in relay to lock the door and a watchdog function for tamper detection. It comes with audible and visual indicators along with the blue backlight LCD. Thanks to its IP67 ingress protection, this RFID Reader is waterproof and can be surface-mounted.
Brand: Dahua
SKU: DHI-ASR1100B
In The Box
DHI-ASR1100B RFID Reader (Wiegand)
Special Feature: RFID Reader with IP67 Ingress Protection for outdoor use
Dimensions: 2.83 x 4.02 x 0.71 inches
Power: 9 VDC to 15 VDC, 100 mA
Transmission: To Controller: RS485
Service: No monthly fee
System
Main Processor: 8-bit
LCD Display: Blue Backlight
Audible Indicator: Buzzer
Reader
Format: 13.56 MHz MIFARE
Distance: 6 to 8 cm (2.36 to 3.15 in.)
Response Time: < 0.1 s
Interface
To Controller: RS485
Certification
Safety:
EN 60950-1:2006+A11:2009+A1:2010+A12:2001+A2:2013
Conforms to UL Standards
Electromagnetic Compatibility(EMC):
FCC CFR 47 Part 15 subpart B
EN 55032:2015
EN 55024:2010+A1:2015
EN 50130-4:2011+A1:2014
EN 6100-3-2:2014
EN 6100-3-3:2013
Electrical/Environmental
Power Supply: 9 to 15 VDC, 100 mA
Operating Temperature: -30 to +60° C (-22 to +140° F)
Ingress Protection: IP67, water-resistant
Construction
Color Black
Dimensions: 72.0 x 102.0 x 18.0 mm (2.83 x 4.02 x 0.71 in.)
Net Weight: 0.20 kg (0.44 lb)
Standard: MIFARE S50, 13.56 MHz
Compatibility: ISO/IEC 14443A
Range: Approximately 10 cm (3.94 in.)
